Description
The Digital Ground Resistance Tester Model 6424 performs 2-pole and 3-pole ground resistance measurement. This direct reading tester is auto-ranging, so it automatically seeks out the optimum measurement range. The Model 6424 is easy to use – simply connect the leads, press to measure, and read. The large LCD also indicates low battery status, overrange, and lead reversals.
The Model 6424 comes with 3 safety color coded terminals to aid in easy hookup, measure voltage up to 600V AC/DC and AC current up to 60A with the optional current probe Model MN72.
The Model 6424 is powered by 6 x AA rechargeable NIMH batteries. The Ground Resistance Tester Model 6424 is also available in complete Kits (150ft and 300ft).
Model 6424 Kit (150 ft) – Cat. #2135.58: (Ground Resistance Tester Model 6424 and Test Kit For 3-Point Testing cat. 2135.35) Includes carrying bag, (2) 150 ft color-coded leads on spools (red/blue), (1) 30 ft lead (green), (2) 5 ft color-coded leads (red/blue), (2) 14.5″ T-shaped auxiliary ground electrodes, (1) set of 5 spaded lugs, and (1) 100 ft AEMC® tape measure and a user manual.
Model 6424 Kit (300 ft) – Cat. #2135.59: (Ground Resistance Tester Model 6424 and Test Kit for 3-Point Testing cat. #2135.36) Includes carrying bag, (2) 300 ft color-coded leads on spools (red/blue), (2) 100 ft color-coded leads (hand tied) (green/black), (2) 5 ft color-coded leads (red/blue), (4) 14.5″ T-shaped auxiliary ground electrodes, (1) set of 5 spaded lugs, and (1) 100 ft AEMC® tape measure and a user manual.
